AlisterTech AL-HR11-B243012020 Top-Emitting LED Neon Flex

AL-HR11-B243012020 references the 10 x 10 mm profile pictured on catalogue page 12, profile 1. Compare its listed LED configurations, then confirm the exact light colour, electrical arrangement and connections for your installation.

AlisterTech 10 x 10 mm silicone profile with original product view and dimensioned source illustration
Profile illustration from AlisterTech source catalogue. Dimensions in mm; electrical configurations are specified separately.

What Is AL-HR11-B243012020?

AL-HR11-B243012020 is an AlisterTech reference for the 10 x 10 mm top-emitting led neon flex profile shown in the International Catalogue. The page groups the configuration rows pictured under profile 1 on page 12; each retains its own full AlisterTech configuration code. The top-emitting geometry is a starting point for upward-facing linear light. Choose the exact row rather than applying one voltage, power or cut length to every variant.

Profile & Dimensions

AlisterTech 10 x 10 mm silicone profile with original product view and dimensioned source illustration
Profile illustration from AlisterTech source catalogue. Dimensions in mm; electrical configurations are specified separately.
ReferenceProfile detail
AlisterTech referenceAL-HR11-B243012020
Catalogue sourceHR11-B243012020
Profile familyTop-Emitting LED Neon Flex
Profile size10 x 10 mm

The reference uses the full catalogue code, not a code derived from profile dimensions.

LED Configuration Table

Each line below is a separate listed LED configuration of the pictured mechanical profile. Include the full configuration code in your enquiry.

AlisterTech configurationLED typeLEDs/mColourCRICut lengthlm/mPCBVoltageW/mFinished size (mm)IP
AL-HR11-B243012020SMD2835120White / Red / Blue Green / Yellow>80/9050mm7006mmDC24V105000*10*10IP67
AL-HR11-B24TW28020SMD22162802700-5500K>9050mm6806mmDC24V105000*10*10IP67
AL-HR11-B24RGB12020SMD3838120RGB/50mm3306mmDC24V105000*10*10IP67

Specifications vary by LED configuration and model. Confirm the final quoted configuration and current technical documentation before ordering. A slash is reproduced where the catalogue does not give a CRI value. The * notation and finished-size values are retained as printed; do not treat the first size value as a maximum single-feed length.

IP67 is listed for these catalogue configurations. Confirm the complete quoted assembly, cable exits and end treatment for the intended exposure; the table is not a separate test report or certification.

Review the Emitting Face & Route

Start with the visible aperture and available width and depth. Position the upward-facing emitting surface toward the intended view or reflected surface. After selecting the profile geometry, compare the individual LED configuration: light colour, density, CRI, cut length, PCB width, voltage, power and finished assembly rating. Review the strip, profile, end treatment and mounting together. A top-emitting face does not, on its own, establish a bending plane or minimum bend radius.

What to Show on the Drawing

  • Visible emitting face and viewing direction
  • Available section width and height
  • Curve, corners and mounting route
  • Cable exits, power location and control method
  • Required length and project quantity

Applications to Review

Coves & ceiling lines

Confirm the installation detail with the selected configuration.

View application

Furniture integration

Confirm the installation detail with the selected configuration.

View application

Architectural details

Confirm the installation detail with the selected configuration.

View application

Accessories & Technical Documents

Accessory compatibility should be confirmed against the selected profile before quotation. Matching dimensions alone do not establish the correct end cap, cable exit or mounting fit.

Use the exact profile and configuration when discussing your project. The International Catalogue contains the complete model rows; accessory documents support a separate fit review.

Manufacturing & Custom Details

White silicone profile being checked at extrusion tooling during a production trial
Silicone profile at extrusion tooling during a production trial. This photograph does not establish equipment capacity or a model-specific test result.

From an Existing Profile to a Custom Detail

Start with a catalogue profile when its section fits. If the groove, emitting face, strip space or end interface needs a different geometry, send a drawing, installation sketch or physical sample for custom silicone extrusion review.

Compare Another Profile

Real illuminated linear lighting samples arranged for visual review

Discuss AL-HR11-B243012020 for Your Installation

Send the exact configuration code, section drawing, light appearance and quantity. Include mounting and cable-exit requirements so the complete quotation can be reviewed.

Request a Quote
