Slim Format
4 × 8 mm Super-Thin LED Neon Flex
- Profile
- Slim rectangular
- Size
- 4 × 8 mm
- Bend
- Installation route review required
- Light
- Single emitting face
LED Neon Flex
LED Neon Flex for Continuous Lines of Light
Finished flexible lighting with an integrated LED source for architectural details, signage and display projects. Compare the profile and exact light configuration, or share your drawing for a custom silicone section.
Profile Selection
Featured LED Neon Flex Formats
Explore slim, broad-face and round formats. Open the product page to compare its exact electrical configurations.
Wide Emitting Face
11 × 6 mm COB LED Neon Flex
- Profile
- Wide rectangular
- Size
- 11 × 6 mm
- Bend
- Installation route review required
- Light
- 11 mm emitting surface
Round Format
16 mm Round LED Neon Flex
- Profile
- Round
- Size
- 16 mm diameter
- Bend
- Installation route review required
- Light
- Confirm selected light appearance
PROFILE FAMILIES
Find the Right LED Neon Flex Format
Choose the light-emitting geometry and section, then compare the configuration options for that profile.
Top-Emitting LED Neon Flex
Upward-emitting sections
Compare profiles & configurations
Side-Emitting LED Neon Flex
Vertical-face light output
Compare profiles & configurations
Black LED Neon Flex
Dark exterior housing
Compare profiles & configurations
Round & Semi-Round LED Neon Flex
Round and semi-round sections
Compare profiles & configurationsLIGHT & POWER OPTIONS
Match the Configuration to Your Supply
Voltage and control options belong to the selected configuration, rather than the profile size.
COLOUR CONTROL
RGB or Pixel RGB
Compare the two configuration types and match the controller to the required colour effect.
View catalogue configurations12V PIXEL OPTIONS
Selected Pixel RGB Rows
These profiles list 12V Pixel RGB. Their single-colour and RGB rows are 24V.
24V OPTIONS
Slim & Round Sections
Compare the exact electrical and light-colour rows for the section you need.
More catalogue section references
More Profile Sizes & Configurations
Compare the section and available light options, then open the profile for its exact configuration table. Send the full configuration code with your enquiry.
Top-emitting
AL-HR11-B243012024
- Section
- 14 × 14 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Side-emitting
AL-HR11-B243012005
- Section
- 6 × 16 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Top-emitting
AL-HR11-B243012081
- Section
- 15 × 10 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Side-emitting
AL-HR11-B243012004
- Section
- 6 × 13 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Black housing
AL-HR11-B243012045
- Section
- Ø22 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Round & semi-round
AL-HR11-B243012037
- Section
- 13 mm semi-round
- Light options
- Single colour · 2700–5500K · RGB
- Supply
- 24V across listed configurations
Top-emitting
AL-HR11-B243012028
- Section
- 20 × 14 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V across listed configurations
Top-emitting
AL-HR11-B243012030
- Section
- 20 × 20 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V across listed configurations
Side-emitting
AL-HR11-B243012006
- Section
- 10 × 18 mm
- Light options
- Single colour · RGB · Pixel RGB
- Supply
- 24V: single colour / RGB
12V: Pixel RGB
Light options are separate configurations. Check the selected row for voltage, power and cut length. Profile images show catalogue sections; emitting orientation does not determine the permitted bending plane.
Bending Direction
Follow the Shape of Your Installation
Top-bend and side-bend describe the permitted bending plane, not simply the direction in which a product emits light. Share a drawing showing both the curve and the emitting face.
01
Top-Bend LED Neon Flex
For a project requiring a top-bend format, show the intended curve and the orientation of the light surface. The selected profile must follow that path without twisting.
Include the mounting surface and the tightest curve in your drawing.
02
Side-Bend LED Neon Flex
For a project requiring a side-bend format, identify the lateral path and the face that remains visible after installation. Select the bending direction together with the assembly details.
Identify corners, transitions and the planned cable exit.
STANDARD & CUSTOM SUPPLY
Choose What You Need Supplied
AlisterTech supplies finished LED Neon Flex and empty silicone housings, with custom silicone extrusion available from your drawing, sample or installation requirements.
LED Neon Flex With an Integrated LED Source
Select the full configuration code, light colour and required lengths. Confirm the controller, power-feed locations and cable exits for the chosen product.
Request a Finished-Light QuoteSilicone Profiles Around Your Installation
For an empty housing or a different cross-section, send the outside shape, strip space and visible light face. Specify housing-only or finished-light supply when requesting a custom section.
Discuss a Custom Silicone ProfileINSTALLATION REVIEW
Prepare the Detail for Your Quote
One marked-up drawing helps us review the profile, mounting and end connections together.
Show the Route & Light Face
Mark the curve, emitting face, installation space and tightest turn on one drawing. Bending direction is checked separately from light direction.
Check top-bend & side-bendDefine Mounting & Access
Show fixing surfaces, supports, transitions and access to joins so the selected profile can be reviewed in its intended position.
Review installation detailsLocate Connections & Power
Provide the end view, cable-exit direction, power-feed positions and controller reference. Confirm the supplied connections with the quotation.
Review end connectionsBefore You Order LED Neon Flex
Does LED Neon Flex include the LED strip?
Finished LED Neon Flex includes the LED light source. AlisterTech also supplies empty silicone housings, which are selected separately from the strip. State which product scope you need when requesting a quote.
Can the silicone profile be customized?
Yes. AlisterTech supports custom silicone extrusion from a drawing, sample or installation requirements. Provide the section, strip space and light face, and specify whether you need the empty housing or a finished lighting assembly. The quoted configuration defines the supply scope.
Which model details should I send for a quotation?
Send the full configuration code rather than only the section size. Include the required colour, segment lengths, quantity, installation drawing, controller reference and power-feed positions so the electrical and connection details can be reviewed together.
Does side-emitting mean the product bends sideways?
The emitting face and permitted bending plane are separate selection details. Mark both on your drawing and show the tightest curve. The selected model and route need to be checked together before ordering.
Request a Quote
Tell Us About Your Neon Lighting Project
Have a model code or a custom-section drawing? Send it with your required quantity and project detail for a product quotation.
